Energy saving lamp ip65 40w solar led street light outdoor

Energy Saving Lamp Ip65 40w Solar
  • Seller Yangzhou Ruiyun Solar Technology Co., Ltd.
  • Min. Order 5 Piece/Pieces
  • FOB Price US $80-310 /Piece

Item Details

Port: Shanghai
Supply Ability: 3000 Piece/Pieces per Month led solar street light
Payment Terms: L/C,T/T

Product Description

Specification
Setting Information
solar panel
120w
rated voltage
220V
Gel Battery
100Ah
LED Fitting
40w
Controller
24v5A
Light pole
7m
Accessories
75MM
Shelf life
5 years
Product Description

Solar Panel-120W

Model NO.:RYDJ-120D
Silicon Type: Polycrystalline silicon cell
Output Power :120 W
Output power tolerance:0%—+3 %
Vmpp(nominal voltage):35V
Impp(nominal current):3.43V
Voc(voltage open circuit): 43 V
Isc(short-circuit current): 3.69 V
Operating Temperature:-40℃~85℃


GEL Battery

Battery Type: Free maintenance Gel deep recycle battery
Capacity(10hr,1.80V/Cell,25℃):100AH
Rated Voltage:12V
Interior Resistance (Completely Charge):5.1mΩ 25℃
Max.Discharge Current: 30I10A (3min)
Self-Discharge(25℃): <2%/ month
Using Temperature: Discharge:-45℃~60℃

LED fitting-40W

Model NO.:RY-L740
Power: 40W (American Bridgelux Chip)
Rated Voltage :12 V
Luminous Flux: 3000 lums
Efficiency: 100 lm/w
Color Rendering Index: >75
LED Wp and quantity:15*10*1 W
Color Temperature :3000k-5000 k available
Work Life: >50000Hrs

Controller-10A

Model NO.:RY-L740
Type: waterproof constant current output controller
Rated working voltage :DC12V
Self consumption:Average static power consumption 7mA;
Max. charging current :10A
Max Convesion Efficiency:94%
Working temperature: -35~60℃
Charging mode: MCT mode (Automatically tracing solar panel’s Max. charging current)
Working mode: Light controlling+time controlling;

Battery Box

Size:470mm*235mm*270mm
Model NO.:RY-L740
Type: Buried Material:ABS plastic
Protection:anti-corrosion, waterproof

Accessories

Size:260mm*750mm*M16
Features :Demountable parts, easy to transport and installation, with screws, customers don't need to weld

Foot Cage

15meter*2.5mm² cables,bolts and other accessories
Installation Process
Applications
Certifications
Company Information
FAQ

1. Are you factory direct?

Rui Yun Tech as a professional solar lighting manufacturer, established in 2001, specialize in LED solar street light, wind and solar street lights complementary light, and other LED lights. Our products are mainly exported to USA, Canada, Europe, South America, etc over 120 countries and area. Rui Yun's mission is contribute the green energy, structure harmonious society.

2. Do you have a special price and service for wholesale?

Rui Yun Tech is keeping search a long term business cooperation with our clients. As a professional solar lighting manufacturer, we can OEM& ODM for our clients, fully support and assist on service, to offer you the most competitive price with high quality is our response.

3、what payment methods can I use.And how secure is my payment?

Rui Yun Tech accept your payment through T/T, Western Union ,Paypal
etc.

4、How long does it take for my order to be shipped? And how long can I receive it?

Generally, your order will be shipped within 4- 9 working days after your payment received by us. Rui Yun Tech devotes to be a faster delivery solar street light supplier.

5、Do you offer guarantee for the products?

Yes, we offer 2-5 years warranty to our products.

6、Is it OK to print my logo on led light product?

Yes, Please inform us formally before our production and confirm the design firstly based on our sample.

7、Can I have a sample order for led light?

Yes, we welcome sample order to test and check quality.
